10X40 & 8X10 TEE – ADA Public Access /ADA Fishing Dock complete with 4‘ x 30‘ Aluminum Gangway (100 psf) and anchorage system.

Includes: (3) Wheelchair Accessible fishing locations, (3)  4′ benches,  perimeter ADA  railing with top fish rail/handrail, heavy duty 12″ galvanized steel truss framing, COE approved polyethylene encased flotation ,  90% recycled environmentally friendly composite decking, (2) telescopic pipe anchors or chain anchor system (less concrete anchors).  Deck/Flotation live load is 30psf.   Choose 40’ x 20’ TEE Design or 60’ Inline Design.

INSTALLATION: Dock sections are shipped in (1) 8 x 20 and (2) 10 x 20 ready–to-float modules with floats, frame, decking and fascia factory assembled.  Anchor components,railings and benches are factory prepared for easy attachment to dock.  All holes are factory punched and all fasteners furnished.

USE:  The perfect solution for fishing and nature/wildlife observation for families, groups and those with special needs.

GSA Part #: Z.FD.GW.4X60 is equipped with a 4×60 foot AL Gangway

GSA Part #: Z.FD.GW.4×30 is equipped with a 4×30 foot AL Gangway

Marine  Co., Inc.  DBA HDB Marine   GSA #  GS-07F-6580W
